LED Neon Flex

LED Neon Flex 3 Face View-M：14X12 IP68 Solid Waterproof

LED Neon Flex Lights feature a flexible design, gentle emitting ,high color consistency, IP68 waterproof .Applications include marine lighting, underwater lighting, outdoor deck lighting, shop mall lighting, and architectural lighting.

LED Neon Flex 3 Face View-M：14X12 IP68 Solid WaterproofPRICE QUOTING
Home Product LED Neon Flex

Specifications

(1).High quality and high brightness SMD LED chip.
(2).Variety of monochromatic lights for option including Red,Green,Blue,Yellow,Pink,Orange, Violet and whitelight.
(3).Flat profile,good choice for recessed mounting.
(4).Environmentally friendly&energy efficient.
(5).High color consistency&smooth illumination With invisible light dots.
(6).Perfect softness,gentle emitting,Not dazzling.
(7).3-5 years warranty.
LED Neon Flex 3 Face View-M：14X12 IP68 Solid Waterproof Technical Specifications

LED Neon Flex 3 Face View-M：14X12 IP68 Solid Waterproof

  Model No. Colour LED
Model 		LEDs/M CCT/
Wavelength 		Power
(W/M) 		Lumens
(lm/M) 		CR Minimum
Cutting
Length(mm) 		FPC
Width
(mm) 		Maximum
connection
length
NF-C27240C-S 2700K 2835  240  2600-2800 12.0  825  90  25  10  15M
NF-C30240C-S 3000K 2835  240  2850-3300 12.0  830  90  25  10  15M
NF-C40240C-S  4000K 2835  240  3850-4400 12.0  839  90  25  10  15M
NF-C50240C-S  5000K 2835  240  4800-5400 12.0  840  90  25  10  15M
NF-C65240C-S  6500K 2835  240  5600-7000 12.0  836  90  25  10  15M
NF-CRE240C-S  Red 2835  240  620-625nm 12.0  300  一 25  10  15M
NF-CGR240C-S Green 2835  240  520-525nm 12.0  380  一 25  10  15M
NF-CBL240C-S Blue 2835  240  460-465nm 12.0  190  一 25  10  15M
NF-CYE240C-S  Yellow 2835  240  590-595nm 12.0  670  一 25  10  15M
NF-CPI240C-S Pink 2835  240  一 12.0  630  一 25  10  15M
NF-COR240C-S  Orange 2835  240  600-610nm 12.0  250  一 25  10  15M
NF-CTW240C-S WW-CW 2835  240  2700-6500 2*10 665  90  50  10  12M
NF-GRG120CS RGB 3535  120  RGB 14.0  500  一 50  10  10M
NF-JRW180C-S RGBW 3535+3014 180  RGBW 16.0  630  一 55.5  10  7.5M
NF-GRG096C-S RGB 3535  96  Pixel RGB 14.0  480  一 62.5  10  7.5M


Specification Data
