LED Wall Washer

LED Wall Washer 2835-40D-22MM-24V PU IP68 Solid Waterproof

LED Wall Washer Linear Lights are expertly designed to elevate wall aesthetics, creating a captivating ambiance in any environment.
Adopting PU glue material, it's resistant to yellowing, weak acid and alkali, and has great flexibility.
It is small in size, light in weight,flexible and easy to install.

LED Wall Washer 2835-40D-22MM-24V PU IP68 Solid WaterproofPRICE QUOTING
Home Product LED Wall Washer

Specifications

(1)Capable of running up to 33 feet (10 meter) without experiencing a voltage drop.
(2) Compact size makes it effortlessly concealable.
(3) Suitable for exterior lighting,commercial lighting,hospitality lighting,facade. lighting,architectural lighting.
(4)Variety beam angle for option: 15°,30°,45°,60°,Asymmetric 25°，15*45°.
(5)Warranty:3-5 Years.
LED Wall Washer 2835-40D-22MM-24V PU IP68 Solid Waterproof Technical Specifications

LED Wall Washer 2835-40D-22MM-24V PU IP68 Solid Waterproof

Model No. CCT Voltage
(V) 		LED
Model 		LEDs/M Power
(W/M)
 Lumens
（lm/M）

 CRI Mini Cutting Length
(mm) 		FPC Width
(mm) 		Maximum connection length(M)
XF-C27040C 2700K DC24V 2835 40 16.0 1600 80 25 16 15
XF-C30040C 3000K DC24V 2835 40 16.0 1610 80 25 16 15
XF-C40040C 4000K DC24V 2835 40 16.0 1630 80 25 16 15
XF-C50040C 5000K DC24V 2835 40 16.0 1640 80 25 16 15
XF-C65040C 6500K DC24V 2835 40 16.0 1620 80 25 16 15

Specification Data
